Qualities
Effective and Adaptable
Due to their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction, they are widely utilized in civil engineering.
Unique Chassis
Roller type big diameter slewing bearings and a telescopic huge widening chassis for rotary drilling rigs ensure exceptional stability when digging deep boreholes.
Cost-effective and energy-efficient
solidly powered imported large displacement EFI engine that uses power optimization control technology, real-time power distribution adjustment, quick response time, increased fuel efficiency, and energy savings.
Superior Dependability
The sixth-generation Kelly bar uses improved material and a stronger block ring; the mast has a box structure that is robust against torsion and fatigue; and the total strength increased.
Parameters
Main Chassis
Base Engine – Isuzu 6WG1
Engine Power – 300/1800kW/rpm
Emission Regulation – China Stage Ⅲ
Rotary Drive
Rated Speed – 5~24rpm
Rated Output Torque – 285kN·m
Pile
Max. Pile Diameter – 2300mm
Max. Pile Depth – 94/61m
Crowd System
Crowd Force – 260kN
Stroke – 6000mm
Line Pull – 335kN
Overall Machine
Overall Height – 25425mm
Operating Weight – 100T
Transport Width – 3490mm
Transport Height – 3690mm
Main Winch
Lifting Capacity – 330kN
Max. Line Speed – 72m/min
Rope Diameter – 36mm
Request for quote: +971525384269
Price: AED3328000
